Features:

· Maximum Reel Weight: 3700kg (Single Cylinder)/4200kg (Double Hoisting Cylinder)

· Maximum Splicing Speed: 250 m/min-300m/min (long frame)

· Splice tail:10mm

· Maximum Paper Speed: 450mpm

· Min/Max Paper tension: 250/850 N

· Splice Head: Fixed in machine center

· Splice Preparation Head: Mobile by manual commands

· Accelerator Roll: Included

· Brakes: Fosber design integrated in the arms

· Chucks: Axial, Torsional or Solid

· Maximum Roll Diameter: 1500mm

· Minimum Roll Diameter in Loading Condition: 350mm

· Minimum Reel Width: 900 mm for 2.5m format/TBD for 2.8m format

· Touch-screen: Included if stand-alone machine

· Minimum Bridge height: 2550 mm
